Power Commander V

Power Commander V        Basic Features List

• Reduced size from PCIIIusb (less than half of the size of PCIII)
• USB powered from computer (9 volt adapter is no longer needed for programming)
• 2 position map switching function built in (map switch not included)
• Gear/Speed input (allows for map adjustment based on gear and speed)
• Analog input (allows user to install any 0-5 volt sensor and build an adjustment table based on its input such as boost or temperature)
• With gear position input connected the PCV is capable of allowing each cylinder to be mapped individually and for each gear (for example: on a 4 cylinder bike with a six speed transmission there could be up to 24 separate fuel tables).
• Unit has a -100/+250% fuel change range (up from -100/+100%). This allows more adjustment range for 8 injector sportbikes
• 10 throttle position columns (up from 9 on PCIIIusb)
• Enhanced “accel pump” utility (increased adjustment and sensitivity ranges)

Harley Davidson Units Also Include:

• Fuel and Timing control
• Rev Xtend
• “Warm Up” fuel adjustment (unit reads engine temp and allows fuel/timing adjustments based on it)
• Software will display J1850 data from bikes’ stock ECU (this is data such as temp, fuel pulse width, timing advance, spark knock, etc.)  more info:

Auto Tune for PCV (all models)

• “Auto Tune” kit is available that includes Wide Band O2 sensor(s) and control box(es). It plugs directly into the PCV and allows automatic fuel adjustments.
• It can make a map for each gear and on Harley Davidson models it can map each cylinder separately for each gear if needed. (basic settings would make one map for all gears)
• Each map cell is individually adjustable so you can specify an exact AFR value for each area if needed.          for ordering and    more info:

year / model

part #

retail

our price

Aprilla

Ducati

Harley Davidson

Honda

Kawasaki

Suzuki

Triumph

Yamaha
